Bircher

BIRCHER EsMatix 3 Safety Switching Device For Sensors With 8,2kΩ - 364283

(No reviews yet) Write a Review
Availability:
Usually ships in 24 hours
Minimum Purchase:
1 unit
340,00€

Out of stock

Description

EsMatix 3
Safety Switching Device For Sensors With 8,2kOhm


TECHNICAL DATA
Supply Voltage : 24 VAC -20% to +10%
                           24 VDC -20% to +20%

Power Consumption : max. 3 VA

Input Sensors : for Sensors with 8,2kOhm termination

Input Reset : 24 V AC/DC

Safety relays : Solid state relays, 24 VDC, max. 250 mA, internally protected by a 300 mA fuse

Status output : Solid state relays, 24 V AC/DC, max. 250 mA

Reaction time (at activation) : < 5 ms

Recovery time : < 30 ms (reset after activation)

Start-up time : < 300 ms

External reset pulse (required) : > 100 ms

Housing Polyamide : grey / red

Dimensions (W x H x D) : 22,5 x 94 x 88 mm

Mounting : Direct DIN-rail mounting

Terminals : Pluggable screw terminals

Protection class: IP30

Operating temperature : –20°C to +60°C

Storage temperature : –40°C to +70°C

Humidity Max.: <95% non-condensing
